Specifications, included items and product information.
- Long-term accuracy thanks to integrated LED light system with reliable cutting-line indication. Easy workpiece control for different material sizes due to detachable workpiece support and long extensions. Effortless cutting – even for large pieces of wood – thanks to strong cutting capacity driven by powerful motor
Technical data
Additional data
Rated input power
1,800 W
Saw blade diameter
305 mm
Mitre setting
52 ° L / 60 ° R
Bevel setting
47 ° L / 47 ° R
Saw blade bore diameter
25.4 mm
Cutting capacity, 0°
105 x 340 mm
Cutting capacity, 45° mitre
105 x 245 mm
Cutting capacity, 45° bevel
340 mm
Tool dimensions (width x length x height)
617 x885 x709 mm
No-load speed
4,050 rpm
Weight
21.4 kg
